Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid cooled, 8 valve, SOHC, 270° crank angle parallel twin
  • Capacity:
    1200 cc
  • Bore:
    3.8 in
  • Stroke:
    3.1 in
  • Compression:
    10.0:1
  • Max Power:
    57 kW / 6100 rpm
  • Max Torque:
    78.2 ft-lb / 4000 rpm
  • System:
    Multipoint sequential electronic fuel injection
  • Exhaust:
    Chromed stainless steel 2 into 2 twin-skin exhaust system with chromed stainless silencers
  • Final Drive:
    Chain
  • Clutch:
    Wet, multi-plate assist clutch
  • Gearbox:
    6-speed
• Chassis

  add remove
  • Frame:
    Tubular steel cradle
  • Swingarm:
    Twin-sided, tubular steel
  • Front Wheel:
    32-spoke, 16 x 2.5in
  • Rear Wheel:
    32-spoke, 16 x 3.5in
  • Front Tyre:
    MT90B16
  • Rear Tyre:
    150/80 R16
  • Front Suspension:
    KYB 41 mm forks with cartridge damping. 90mm travel.
  • Rear Suspension:
    KYB monoshock with linkage and stepped preload adjuster, 72 mm rear wheel travel.
  • Front Brake:
    Twin 310 mm disc, Brembo 2-piston floating calipers, ABS
  • Rear Brake:
    Single 255 mm disc, Nissin single piston floating caliper, ABS
• Dimensions & Weights

  add remove
  • Width Handlebars:
    35.8 in
  • Height Without Mirror:
    41.5 in
  • Seat Height:
    27.8 in
  • Wheelbase:
    59.1 in
  • Rake:
    25.3 º
  • Trail:
    3.6 in
  • Tank Capacity:
    3.2 gal
  • Wet Weight:
    263 kg
• Fuel Consumption

  add remove
  • Fuel Consumption:
    4.3 l/100 km (66 MPG)
  • CO₂ Figures:
    105 g/km EURO 5 CO_{2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real dr}
