Specifications

• ENGINE

  add remove
  • Engine Type:
    Horizontal In-line
  • Cylinders:
    4
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    16
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    2.76
  • Stroke (in):
    1.92
  • Displacement (cc):
    750
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    12.5:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
  • Overdrive:
    No
  • Gear Ratio (1):
    2.785
  • Gear Ratio (2):
    2.052
  • Gear Ratio (3):
    1.714
  • Gear Ratio (4):
    1.5
  • Gear Ratio (5):
    1.347
  • Final Drive Ratio:
    2.647
  • Gear Ratio (6):
    1.208
  • Primary Drive (Engine / Transmission):
    Gear
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    79.9
  • Width (in):
    28
  • Height (in):
    44.7
  • Wheelbase (in):
    54.7
  • Ground Clearance (in):
    5.1
  • Fuel Capacity (gal):
    4.5
  • Turning Radius (ft):
    11.2
  • Wet Weight (lbs):
    419
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.6
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Front Travel (in):
    4.7
  • Rear Travel (in):
    5.1
  • Front Suspension Brand Name:
    Showa® BPF
  • Steering Damper:
    Yes
  • Rear Suspension Brand Name:
    Showa®
  • Rear Suspension Size (in):
    1.6
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    Bridgestone® Battlax 120/70 ZR17M/C 58W
  • Rear Tire (Full Spec):
    Bridgestone® Battlax 180/55 ZR17M/C 73W
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
  • Front Brake Diameter (in):
    12.2
  • Brake Brand Name:
    Brembo® Monobloc
