Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Engine Stroke:
    4-Stroke
  • Bore (in):
    4.02
  • Stroke (in):
    3.33
  • Displacement (cc):
    690
  • Horsepower (bhp):
    66
  • Compression Ratio:
    12.6:1
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Primary Drive (Rear Wheel):
    Chain
  • Number Of Speeds:
    6
  • Overdrive:
    Yes
  • Gear Ratio (1):
    2.5
  • Gear Ratio (2):
    1.75
  • Gear Ratio (3):
    1.33
  • Gear Ratio (4):
    1.1
  • Gear Ratio (5):
    0.96
  • Gear Ratio (6):
    0.87
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    59.2
  • Ground Clearance (in):
    11
  • Ground Clearance (mm):
    280
  • Dry Weight (lbs):
    308.6
  • Fuel Capacity (gal):
    3.2
  • Fuel Capacity (l):
    12
  • Engine Displacement to Weight (cc):
    2.24
  • Fuel Capacity Reserve (gal):
    0.7
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.9
  • Front Travel (in):
    9.8
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    9.8
  • Number Rear Shock Absorbers:
    1
  • Front Suspension Brand Name:
    WP
• WHEELS & TIRES

  add remove
  • Front Tire Width:
    90
  • Front Wheel Diameter:
    21
  • Rear Wheel Diameter:
    18
  • Front Tire (Full Spec):
    Pirelli® MT 21 Rallycross 90/90 R21 54R
  • Rear Tire (Full Spec):
    Pirelli® MT 21 Rallycross 140/80 R18 70R
  • Rear Tire Width:
    140
  • Front Tire Aspect Ratio:
    90
  • Rear Tire Aspect Ratio:
    80
  • Front Tire Speed Rating:
    54R
  • Rear Tire Speed Rating:
    70R
• BRAKES

  add remove
  • Front Brake Type:
    Disc
  • Front Brake Diameter (in):
    11.8
  • Rear Brake Type:
    Disc
  • Rear Brake Diameter (in):
    9.5
