Specifications

• ENGINE

  add remove
  • Engine Type:
    In-Line
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Bore (in):
    3.43
  • Stroke (in):
    2.5
  • Displacement (cc):
    755
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Bore And Stroke:
    87.0mm x 63.5mm
  • Induction:
    Programmed Fuel injection (PGM-FI); 46mm throttle body
  • Compression Ratio:
    11.0:1
  • Valve Train:
    Unicam SOHC; four valves per cylinder
  • Final Drive:
    #520 Chain; 16T/45T
  • Transmission:
    Six-speed
• Chassis/ Suspension/ Brake

  add remove
  • Front Suspension:
    Dual 310mm discs; 2-channel ABS
  • Rear Suspension:
    Single 256mm disc; 2-channel ABS
  • Front Tire:
    90/90-21
  • Rear Tire:
    150/70-18
• Dimensions

  add remove
  • Rake:
    27.0°
  • Trail:
    4.4 inches
  • Wheelbase:
    61.5 inches
  • Seat Height:
    33.7 inches (optional 32.6-inch accessory seat available)
  • Curb Weight:
    459 pounds (Includes all standard equipment, required fluids and full tank of fuel—ready to ride)
  • Fuel Capacity:
    4.5 gallons
• Other

  add remove
  • Emissions:
    Meets current EPA and California Air Resources Board (CARB) standards.
• Factory Warranty Information

  add remove
  • One Year Included:
    Transferable, unlimited-mileage limited warranty
  • Optional Extended:
    Extended coverage available with a HondaCare® Protection Plan
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    61.5
  • Fuel Capacity (gal):
    5
  • Fuel Capacity Reserve (gal):
    1
  • Length (in):
    91.2
  • Width (in):
    33.1
  • Height (in):
    57.2
  • Ground Clearance (in):
    8.3
  • Wet Weight (lbs):
    459
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.7
  • Front Travel (in):
    7.9
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Suspension Material:
    Aluminum
  • Rear Travel (in):
    7.5
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Brand Name:
    Pro Link®
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Tube / Tubeless:
    Tubed
  • Front Tire (Full Spec):
    Metzeler Karoo Street: 90/90 - 21 54H
  • Rear Tire (Full Spec):
    Metzeler Karoo Street: 150/70 -18 70H
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.2
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.1
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
