Specifications

• ENGINE

  add remove
  • Engine Type:
    Parallel Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Bore (in):
    3.43
  • Stroke (in):
    2.5
  • Displacement (cc):
    755
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Engine Brand Name:
    Honda
  • Compression Ratio:
    11.0:1?
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    55.9
  • Fuel Capacity (gal):
    4
  • Fuel Capacity Reserve (gal):
    0.8
  • Length (in):
    82.4
  • Width (in):
    30.8
  • Height (in):
    42.7
  • Ground Clearance (in):
    5.6
  • Wet Weight (lbs):
    422
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    4.7
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Suspension Material:
    Aluminum
  • Rear Travel (in):
    5.1
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Brand Name:
    Pro Link®
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Front Tire (Full Spec):
    Bridgestone® S22: 120/70-17
  • Rear Tire (Full Spec):
    Bridgestone® S22: 180/55-17
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.2
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    9.4
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
  • Brake Brand Name:
    Brembo Stylema®
