The Low Rider® was inspired by the tradition of individualism that came roaring to life in the custom chopper era. The rake on its front end, dual gauges on the tank and ‘70s-inspired graphics leave no doubt about that. Only it’s built for rolling faster, harder and longer than any Low Rider® motorcycle that ever rolled out of the factory. It’s also lighter with the massive, refined power of the Milwaukee-Eight® 107 engine. And lean angles and a suspension that let you carve corners in ways they never imagined back in the day. There’s also just enough modern flash to show the world it belongs to this generation, like cast wheels and LED forward lighting. Take it in your own direction.

Specifications

Dimensions

add remove
- Length:

  92.7 in
- Ground clearance:

  5.1 in
- Rake (steering head):

  30
- Trail:

  6.4 in
- Wheelbase:

  1,630.0 in
- Tires, front specifications:

  110/90B19,62H,BW
- Tires, rear specifications:

  180/70B16,77H,BW
- Fuel Capacity:

  5.0 gal
- Oil capacity:

  5 qt.
- Weight, as shipped:

  633 lbs
- Weight, in running order:

  661 lb
Engine

add remove
- Engine:

  Milwaukee-Eight® 107
- Bore:

  3.9 in
- Stroke:

  4.4 in
- Displacement:

  106.55 in³
- Compression ratio:

  10.0:1
- Fuel system:

  Electronic Sequential Port Fuel Injection (ESPFI)
- Exhaust:

  2-into-2 shotgun; catalyst in muffler
Performance

add remove
- Engine torque testing method:

  J1349
- Engine torque:

  109.9 ft-lb
- Lean angle, right (deg.):

  29.6
- Lean angle, left (deg.):

  29.6
- Fuel economy testing method:

  Estimated City/Hwy
- Fuel economy:

  0.00 mpg
Powertrain

add remove
- Primary drive:

  Chain, 34/46 ratio
- Gear ratios (overall) 1st:

  9.311
- Gear ratios (overall) 2nd:

  6.454
- Gear ratios (overall) 3rd:

  4.793
- Gear ratios (overall) 4th:

  3.882
- Gear ratios (overall) 5th:

  3.307
- Gear Ratios (overall) 6th:

  2.79
Chassis

add remove
- Wheels, front type:

  Black, machine highlighted, Radiate cast aluminum wheel
- Wheels, rear type:

  Black, machine highlighted, Radiate cast aluminum wheel
- Brakes, caliper type:

  4-piston fixed front and 2-piston floating rear
Electric

add remove
- Lights (as per country regulation), indicator:

  High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS (if equipped), security, low battery voltage, low fuel
- Gauges:

  4-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication; 4-inch analog tachometer
